AMC HCB200S Surface Mount Circuit Breaker 200A

The AMC HCB200S Surface-Mount Circuit Breaker (200A) is a robust, high-capacity thermal circuit breaker designed for demanding DC electrical systems. Ideal for applications such as marine, RV, automotive, and off-grid power systems, it combines circuit protection and manual switching in a single unit.�� Key Features:Current Rating: 200 AmpsVoltage Rating: Up to 48V DCInterrupt Capacity: 3000A @ 30V DCMounting Style: Surface-mount with 3/8″ (M10) terminal studsIngress Protection: IP67 – fully sealed against dust and waterIgnition Protection: Compliant with SAE J1171, suitable for installation in engine compartmentsOperating Temperature: -32°C to 82°CMaterial: Black UL-rated 94V0 thermoplasticReset Mechanism: Manual toggle lever for manual resetApplications: Suitable for high-current circuits in trucks, buses, RVs, and marine systems
