Explosion proof Dome Camera KX-EX2000PSB2, 2MP Fixed Lens

Explosion proof Dome Camera KX-EX2000PSB2 Explosion proof Dome Camera KX-EX2000PSB2 from KAIXUAN has meet all strict explosion proof standard for explosive hazardous environment. Features Explosion Proof Dome Camera KX-EX2000PSB2 is certified to be used in hazardous locations. ATEX Zone 1&2 / 21&22 Class I Division 1&2 / Class II Division 1&2 and all the rest except zone 0. IR distance:15m lens: 4/6/8mm for optional Support ONVIF. apply to strong corrosive environment, Explosion-proof,anti-corrosion, waterproof Adopt SONY1/3″CMOS Senor CCD ,resolution up to 1920×1080 pixel . Adopt TI-DSP CPU . High work efficiency Support dual stream, support mobile phone monitoring Windows glass surface process by nano technology . Well light transmittance. no halation effect .non-stick oil/dusty . Low power consumption, the fuselage internal air convection heat dissipation design, can work continuously for a long time Power supply : DC 12V/POE , other Power mode can be customized Support Power Over Ethernet technology Made of 304 stainless steel material. apply to strong corrosive environment Camera bottom cover adopt Poly carbonate transparent Material . Well design for Explosion-proof, anti-corrosion, waterproof , suitable for indoor and outdoor environment Suitable application of Explosion proof Dome Camera KX-EX2000PSB2 Explosion proof Dome Camera KX-EX2000PSB2 Can be used in extremely situation Such as petroleum, chemical industry, mine, military industry, medicine, oil depot, ships, drilling platform, gas stations, fireworks production, food processing and storage, offshore projects etc Explosion proof Dome Camera KX-EX2000PSB2 Explosion proof standard of Explosion proof Dome Camera KX-EX2000PSB2 ATEX Zone 1&2 / 21&22 Class I Division 1&2 / Class II Division 1&2 and all the rest except zone 0. ATEX II 2G Ex d IIC T6 Gb II 2D Ex tb IIIC IP68 T80℃ Db Specifications Product Ex-level ATEX II 2G Ex d IIC T6 Gb II 2D Ex tb IIIC IP68 T80℃ Db Ingress  Protection level IP66 Camera imaging  sensor  SONY1/3″CMOS Senor CCD Cpu TI-  DSP minimal  illumination Color  [email protected],  BW  0.01 [email protected]; Lens  specification 2.8mm, 4mm、6mm、8mm  etc Optional DNR 3D –DNR motion  detecting Support compression  standard Video  compression standard H.264/H.265/MJPEG H.264  encoding type BaseLine  Profile / Main Profile compression  output rate 32  Kbps~8Mbps Image Max  imaging size 1920×1080 Frame  rate 2  megapixel and following 25 frame(full-time), support 1~25 fps is adjustable; Video  output Main:1920×1080,1600×1200,1280×1024,1280×960,1024×768,1280×720; Sub: 640×360,480×270,352×288,320×240,352×192,320×192,288×192,256×192; Image setting  Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser IR IR distance 15m IR switch IR lamp Auto-open when <0 Lux wavelength 850nm Net Interface  protocols ONVIF,PSIA,CGI,ISAPI,GB28181 Support  protocols RTSP/FTP/PPPOE/DHCP/DDNS/NTP/  UPnP  etc . audio  interface Optional Alarm  interface Optional Other  specifications Temperature  range -40℃～60℃ Relative  humidity ≤95%（ 25°C） Atmospheric  pressure 80kpa～106 kpa Thermostat System Optional Supply  voltage DC12V/POE(Optional) Suitable  environment Apply  to explosive gas and combustible dust environment Material 304 stainless  steel(316, 316L for optional) Inlet hole  specifications 1pcs M20*1.5(original 1* G1/2″ ) Installation  method Wall Hanging  dyadic , fixed bracket Dimension Drawing of Explosion proof Dome Camera KX-EX2000PSB2 Related Accessories of Explosion proof Dome Camera KX-EX2000PSB2 Explosion proof conduit pipe Explosion proof conduit pipe-304/316L stainless steel explosion proof junction according to project
