8MP 4K 2.8-12mm zoom lens Explosion proof camera,KX-EX707PWG8

Feature Specification Accessories Drawing Download Contact us 8MP 4K 2.8-12mm zoom lens Explosion proof camera,KX-EX707PWG8 8MP 4K 2.8-12mm zoom lens Explosion proof camera KX-EX707PWG8 is certified for explosive environment. we can also provide SS316L marine grade version for offshore environment. It built in 8MP 4K high resolution camera inside and have 2.8-12mm zoom lens which can zoom in and out. Feature ATEX Zone 1, Zone 2, Zone 21, Zone 22. Class I Division 1, Class I Division 2, Class II Division 1, Class II Division 2. Support ICR Day/Night Auto-switch, Color- BW, 24 hours monitoring High quality IR lamp, long service life, irradiation distance up to 30 meters. Support digital wide dynamic, support 3D-DNR function Support dual stream, support mobile phone monitoring Windows glass surface process by nano technology. Well light transmittance. no halation effect. non-stick oil/dusty. Low power consumption, the fuselage internal air convection heat dissipation design, can work continuously for a long time Power: DC12V/POE, other Power mode can be customized. Made of 304/316L stainless steel material. apply to strong corrosive environment Suitable application for 8MP 4K 2.8-12mm zoom lens Explosion proof camera Can be used in extremely situation Such as petroleum, chemical industry, mine, military industry, medicine, oil depot, ships, drilling platform, gas stations, fireworks production, food processing and storage, offshore projects etc explosion proof standard of 8MP 4K Explosion proof camera with 2.8-12mm 4x zoom lens ATEX II 2G Ex db IIC T6 Gb II 2D Ex tb IIIC IP68 T80℃ Db it can be used in ATEX Zone 1, Zone 2, Zone 21, Zone 22. Class I Division 1, Class I Division 2, Class II Division 1, Class II Division 2. Specification Product Ex-Level ATEX II 2G Ex d IIC T6 Gb II 2D Ex tb IIIC IP68 T80℃ Db Ingress Protection level IP66 Camera imaging sensor 1/2.7″CMOS DSP TI-DSP minimal illumination Color [email protected], BW0.01 [email protected]; Day/Night IR-CUT auto-switch DNR 3D focal distance  2.8-12mm Aperture control  Auto Automatic aperture  DC-drive motion detecting support Compression standard Video compression standard H.265/H.264/MJPEG H.264 encoding type Base Line Profile / Main Profile Video compression standard 32 Kbps~8Mbps Image Maximum resolution 2592*1520 Frame rate 4 million pixels is 20 frames, 2 million pixels and following is 30 fps(full-time), support 1~30 fps is adjustable; Video output Main stream: 2592*1520, 2048×1536, 1920*1080, 1600×1200, 1280×960,1024×768,1280×720; Sub stream: 640×480,640×360,480×360,352×288,320×240 Image setting Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser Net Interface protocols ONVIF,PSIA,CGI,ISAPI,GB28181 Support protocols RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP etc. audio interface optional Alarm  interface optional Laser lamp IR distance 30M IR switch IR lamp Auto-open when <0 Lux wavelength, 808nm Other specification Temperature range -40℃～60℃ Relative humidity ≤ 5%（ 25°C） Atmospheric pressure 80kpa～106 kpa Thermostat System  optional Supply voltage DC12V /POE(Optional) Suitable Environment Apply to explosive gas and combustible dust environment Material 304 stainless steel, 316L for optional Inlet hole specifications 1pcs outlet Installation method PTZ, Wall bracket, fixed bracket , Pillar base Accessories explosion proof junction Box KX-EX09CBD series Explosion proof conduit pipe-304/316L stainless steel 4 way Explosion proof junction box for cable connection; KX-EX08CBS44-A IIC explosion proof Junction Box KX-EX10CBD series Camera universal joint bracket; KX-EX06BS-W Camera bracket; KX-EX06BS Explosion proof conduit pipe Drawing for 8MP 4K 2.8-12mm zoom lens ATEX camera can contact our sales for more info Download for 8MP(4K) 2.8-12mm 4x zoom lens Explosion proof camera for datasheet, drawing, user manual, technical doubts. welcome to contact our sales for more info.
