8MP 4K explosion proof 25x zoom security camera KX-EX707PWY825

feature specification drawing accessories download 8MP 4K explosion proof 25x zoom security camera KX-EX707PWY825 with Wiper 8MP 4K explosion proof 25x zoom security camera KX-EX707PWY825 use 8MP high resolution camera and has meet all strict explosion proof standard for explosive hazardous environment. has wiper function built-in. and have 25x optical and 16x digital zoom lens. Features 8MP 4K explosion proof 25x zoom security camera with wiper is certified to be used in hazardous locations. ATEX Zone 1&2 / 21&22 Class I Division 1&2 / Class II Division 1&2 and all the rest except zone 0. lens: 25x optical and 16x digital zoom lens. 8MP. Support wiper Support ONVIF. apply to strong corrosive environment, Explosion-proof,anti-corrosion, waterproof Support ICR Day/Night Auto-switch , Color- BW , 24 hours monitoring High quality IR lamp , long service life , irradiation distance up to 100 meters. Support 120db WDR. Windows glass surface process by nano technology . Well light transmittance. no halation effect .non-stick oil/dusty . Low power consumption, the fuselage internal air convection heat dissipation design, can work continuously for a long time power: AC220V/DC12V/POE , other Power mode can be customized . Made of 304 or SS316L stainless steel material. apply to strong corrosive environment Well design for Explosion-proof, anti-corrosion, waterproof , suitable for indoor and outdoor environment Suitable application of 8MP 4K explosion proof 25x zoom security camera Can be used in extremely situation Such as petroleum, chemical industry, mine, military industry, medicine, oil depot, ships, drilling platform, gas stations, fireworks production, food processing and storage, offshore projects etc Explosion proof standard of 8MP 4K explosion proof 25x zoom security camera ATEX II 2G Ex d IIC T6 Gb II 2D Ex tb IIIC IP68 T80℃ Db Specifications Product Ex-Level ATEX II 2G Ex d IIC T6 Gb II 2D Ex tb IIIC IP66 T80℃ Db Ingress  Protection level IP66 Camera imaging  sensor 1/2.8″ Progressive Scan CMOS minimal  illumination Color  ：0.001 Lux @(F1.6,AGC ON); BW ：0.0005Lux @(F1.6,AGC ON) Day/Night ICR  auto-switch electronic  shutter 1/25s to 1/100,000s, Supports delayed shutter resolution  ratio 50Hz: 25fps (3840X2160, 2560X1440, 1920X 1080, 1280X960,1280X720); 60Hz: 30fps (3840X2160, 2560X1440, 1920X 1080, 1280X960, 1280X720) third stream: 50Hz: 25fps (704 x 576); 60Hz: 30fps (704 x 576) White  balance 1/2 Auto /  indoor/outdoor/manual/sodium lamp, fluorescent lamp Defog support Lens Focal  distance 5.5-137.5mm, 25x Optical Zoom and 16X digital zoom Aperture F1.6-F3.5 horizontal  view angle 55.3-3.2°(wide-tele) Min-working  distance 100mm-1500mm (wide-tele) Zoom  speed About  3.5 S ( optical ，Wide-Tele) Laser  lamp The  laser wavelength, 808nm Irradiation  distance 60m Menu  control exposure mode Auto  exposure / aperture priority / shutter priority / manual exposure Focusing  mode Auto  /Manual / one time focusing Compression standard Video  compression standard H.264  /h.265/ MJPEG Compression  output rate 32  Kbps~16Mbps Net  Function Memory Support  micro SD Intelligent  alarm motion detecting、fault block alarm、the memory full, memory fault Support  protocols TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,RTP,RTSP,RTCP,NTP,SMTP,SNMP,IPv6 Interface audio  input Optional audio  output Optional Interface  protocols ONVIF、PSIA、CGI Other  specification Temperature  range -40℃～60℃ Relative  humidity ≤ 5%（ 25°C） Atmospheric  pressure 80kpa～106 kpa Material 304  stainless steel(316, 316L for optional) Supply  voltage DC12/AC220V（optional )/POE(Optional) Inlet  hole specifications 2pcs M25*1.5 output(original G3/4) Thermostat  System Optional Installation  method PTZ  ,Wall Hanging dyadic , fixed bracket , Pillar base Drawing of 8MP 4K explosion proof 25x zoom security camera Accessories explosion proof junction Box KX-EX09CBD series Explosion proof conduit pipe-304/316L stainless steel 4 way Explosion proof junction box for cable connection; KX-EX08CBS44-A IIC explosion proof Junction Box KX-EX10CBD series Camera universal joint bracket; KX-EX06BS-W Camera bracket; KX-EX06BS Explosion proof conduit pipe download for 8MP 4K explosion proof 25x zoom security camera
