Explosion proof Camera KX-EX707PW2, 2MP Varifocal

Explosion proof Camera KX-EX707PW2 Explosion proof Camera KX-EX707PW2 from KAIXUAN has meet all strict explosion proof standard for explosive hazardous environment. Features Explosion Proof Camera KX-EX707PW2 is certified to be used in hazardous locations. ATEX Zone 1&2 / 21&22 Class I Division 1&2 / Class II Division 1&2 and all the rest except zone 0. IR distance:60m lens: 2.8-12mm Support ONVIF. apply to strong corrosive environment, Explosion-proof,anti-corrosion, waterproof Adopt SONY1/3″CMOS Senor CCD ,resolution up to 1920 x 1080 pixel . Adopt 2.8-12mm lens , easy to monitor remote targets Support ICR Day/Night Auto-switch , Color- B/W , 24 hours monitoring High quality IR lamp , long service life , irradiation distance up to 60 meters. Support digital wide dynamic, support 3D-DNR function Support dual stream, support mobile phone monitoring Windows glass surface process by nano technology . Well light transmittance. no halation effect .non-stick oil/dusty . Low power consumption, the fuselage internal air convection heat dissipation design, can work continuously for a long time Power supply : DC12V/POE , other Power mode can be customized . Made of 304 stainless steel material. apply to strong corrosive environment Well design for Explosion-proof, anti-corrosion, waterproof , suitable for indoor and outdoor environment Suitable application of Explosion proof Camera KX-EX707PW2 Can be used in extremely situation Such as petroleum, chemical industry, mine, military industry, medicine, oil depot, ships, drilling platform, gas stations, fireworks production, food processing and storage, offshore projects etc Explosion proof standard of Explosion proof Camera KX-EX707PW2 ATEX Zone 1&2 / 21&22 Class I Division 1&2 / Class II Division 1&2 and all the rest except zone 0. ATEX II 2G Ex d IIC T6 Gb II 2D Ex tb IIIC IP68 T80℃ Db Specifications Product Ex-Level ATEX II 2G Ex d IIC T6 Gb II 2D Ex tb IIIC IP68 T80℃ Db Ingress Protection level IP66 Camera imaging sensor SONY 1/2.7″CMOS DSP TI-DSP minimal illumination Color [email protected], BW0.01 [email protected]; Day/Night IR-CUT auto-switch DNR 3D focal distance  2.8-12mm Aperture control  Auto Automatic aperture  DC-drive motion detecting support Compression standard Video compression standard H.264/H.265/MJPEG H.264 encoding type BaseLine Profile / Main Profile Video compression standard 32 Kbps~8Mbps Image Maximum resolution 1920×1080 Frame rate 2 megapixel and following 25 frame(full-time), support 1~25 fps  is adjustable; Video output Main Stream:1920×1080,1600×1200,1280×1024,1280×960,1024×768,1280×720;Sub Stream: 640×360,480×270,352×288,320×240,352×192,320×192,288×192,256×192; Image setting Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser Net Interface protocols ONVIF,PSIA,CGI,ISAPI,GB28181 Support protocols RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP etc. audio interface optional Alarm  interface optional Laser lamp IR distance 60M IR switch IR lamp Auto-open when <0 Lux wavelength, 808nm Other specification Temperature range -40℃～60℃ Relative humidity ≤ 5%（ 25°C） Atmospheric pressure 80kpa～106 kpa Thermostat System  optional Supply voltage DC12V /AC220V（optional ）/POE(Optional) Suitable Environment Apply to explosive gas and combustible dust environment Material 304 stainless steel (316, 316L for optional) Inlet hole specifications 2pcs M25*1.5 output(original G3/4) External dimensions 380mm*144mm*232mm Installation method PTZ,Wall Hanging dyadic , fixed bracket , Pillar base Dimension Drawing of Explosion proof Camera KX-EX707PW2 Related Accessories of Explosion proof Camera KX-EX707PW2 Camera bracket; KX-EX06BS Camera universal joint; KX-EX06BS-W Explosion proof conduit pipe Explosion proof conduit pipe-304/316L stainless steel explosion proof junction according to project
