c1d1 c1d2 explosion proof camera 5MP, KX-EX707PWF

feature specification drawing accessories download c1d1 c1d2 explosion proof camera c1d1 c1d2 explosion proof camera has meet all strict explosion proof standard for explosive hazardous environment. it’s designed and can be used in all types of explosive environment. Features 5 Mega pixel bullet type explosion proof camera. High quality IR lamp , long service life , low power consumption IR  distance up to 30 meters Windows glass surface process by nano technology . Well light transmittance. non-stick oil/dusty /water. Made of 304 stainless steel material. apply to strong corrosive environment Suitable application of c1d1 c1d2 explosion proof security camera Can be used in extremely situation Such as petroleum, chemical industry, mine, military industry, medicine, oil depot, ships, drilling platform, gas stations, fireworks production, food processing and storage, offshore projects etc Explosion proof standard of c1d1 c1d2 explosion proof bullet camera ATEX II 2G Ex d IIC T6 Gb II 2D Ex tb IIIC IP68 T80℃ Db Our camera can be used in ATEX Zone 1&2 / 21&22 Class I Division 1&2 / Class II Division 1&2 and all the rest except zone 0. Specifications Products Ex-Level ATEX II 2G Ex d IIC T6 Gb II 2D Ex tb IIIC IP68 T80℃ Db Ingress Protection level IP66 Camera imaging sensor 1/2.5” CMOS minimal illumination Color [email protected],BW0.01 [email protected]; Lens specification 4mm、6mm etc optional Day/Night IR-CUT auto-switch DNR 3D –DNR Motion detecting support Compression standard Video compression standard H.264/H.265/MJPEG H.264 encoding type Base Line Profile / Main Profile Compression output rate 32 Kbps~8Mbps Image Max resolution 2560*1920 Video output 2560*1920（5M）、2560*1440(4M)、2304*1296(3M)、1920*1080（1080P）、1280*960（960P）、1280*720（720P）、704*576(D1)、640*480(VGA)、352*288（CIF） 、176*144(QVGA) Image setting Rotate mode, Saturation, Brightness, Contrast adjustable by  client software or web browser Net Interface protocols ONVIF,PSIA,CGI,ISAPI,GB28181 Support protocols RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP  etc audio interface Optional Alarm  interface Optional IR IR distance 30M IR switch IR lamp Auto-open when <0 Lux wavelength 850nm Other specification Temperature range -40℃～60℃ Relative humidity ≤ 95%（ 25°C） Atmospheric pressure 80kpa～106 kpa heater Optional Supply voltage DC12V/POE(Optional) Suitable environment Apply to explosive gas and combustible dust environment Material 304 stainless steel， 316L for optional Inlet hole specifications 1pcs M20*1.5 output(original G1/2) Installation method bracket or base installation Drawing of c1d1 c1d2 5MP explosion proof camera accessories explosion proof junction Box KX-EX09CBD series Explosion proof conduit pipe-304/316L stainless steel 4 way Explosion proof junction box for cable connection; KX-EX08CBS44-A IIC explosion proof Junction Box KX-EX10CBD series Camera bracket; KX-EX06BS Explosion proof conduit pipe download for c1d1 c1d2 explosion proof camera
