explosion proof PTZ camera KX-EX1000ZPPS220, 2MP 20X

Explosion proof PTZ Camera KX-EX1000ZPPS220 Explosion proof PTZ Camera KX-EX1000ZPPS220 from KAIXUAN has meet all strict explosion proof standard for explosive hazardous environment. Features Explosion Proof Camera KX-EX1000PPS220 is certified to be used in hazardous locations. ATEX Zone 1, Zone 2, Zone 21, Zone 22. Class I Division 1, Class I Division 2, Class II Division 1, Class II Division 2. horizontal 360°(Endless)，Vertical：±90°，Rotate speed 0.1°/S~40°/s lens: 20x IR distance:100M Support ONVIF. AC85V-260V(DC 24V, AC24V for option) apply to strong corrosive environment, Explosion-proof,anti-corrosion, waterproof smart windshield wiper Support digital wide dynamic,support 3D-DNR, low bit rate The module circuit design, support baud rate/ control protocol automatic recognition, support software address code setting. Imported precision motor, Response sensitivity, stable operation, low accuracy, no jitter under any speed Windows glass surface process by nano technology . Well light transmittance. no halation effect .non-stick oil/dusty Low power consumption, the fuselage internal air convection heat dissipation design, can work continuously for a long time Made of 304 stainless steel material. apply to strong corrosive environment Well design for Explosion-proof,anti-corrosion, waterproof , suitable for indoor and outdoor environment Suitable application of explosion proof PTZ Camera KX-EX1000ZPPS220 Can be used in extremely situation Such as petroleum, chemical industry, mine, military industry, medicine, oil depot, ships, drilling platform, gas stations, fireworks production, food processing and storage, offshore projects etc Explosion proof standard of explosion proof PTZ Camera KX-EX1000ZPPS220 ATEX Zone 1, Zone 2, Zone 21, Zone 22. Class I Division 1, Class I Division 2, Class II Division 1, Class II Division 2. ATEX II 2G Ex d IIC T6 Gb II 2D Ex tb IIIC IP68 T80℃ Db Specifications Products Ex-Level ATEX II 2G Ex d IIC T6 Gb II 2D Ex tb IIIC IP66 T80℃ Db Ingress  Protection level IP66 Camera imaging sensor 1/2.8″ Progressive Scan CMOS Signal System PAL/NTSC minimal  illumination Color ：0.001Lux @ (F1.6，AGC ON) BW ：0.0005Lux @(F1.6，AGC ON) Day/Night ICR  auto switch SNR >52dB electronic shutter 1/1S  ~ 1/30,000S resolution  ratio 50HZ:25fps(1920×1080)   60HZ:30fps(1920×1080) 50HZ:25fps(1280×720) 60HZ:30fps(1280×720) White balance 1/  2Automatic / manual / indoor / outdoor lamp / fluorescent lamp 3D DNR Support Lens focal distance 4.7-94mm，20 optical Digital zoom 16x Aperture F1.6-F3.5 horizontal view angle 61.4-2.9 ° (Wide-Tele ) Min-working  distance 10-1500mm(Wide-Tele) Zoom speed About 2.7 s  (optical ，Wide-Tele) Menu control exposure mode Auto exposure  / aperture priority / shutter priority / manual exposure Focusing mode Auto  /manual /one time focusing Compression standard Video  compression standard H.264 /H.265/MJPEG Output  compression rate 32 Kbps~16Mbps Audio  compression standard G.711-a law、G.711-u law、G.726 Image Image set Saturation,  brightness, contrast Net Memory Support micro  SD Intelligent  alarm motion detecting,fault block alarm、the memory full, memory fault Support  protocols TCP/IP、HTTP、DHCP、DNS、DDNS、RTP、RTSP、PPPoE、SMTP、NTP、UPnP、SNMP、FTP、802.1x、QoS、HTTPS、IPv6 (SIP、SRTP、 Optional PTZ function Rotation  range Horizontal ：0～360°Vertical:   ：±90° Rotation  speed Horizontal ：0.1°/S~40°/s Vertical:   ：0.1°/S~40°/s monitoring location 300  locations can be set Communication  method RS485 Baud rate 2400 / 4800  / 9600 bps Communication  protocol PELCO－D、PELCO－P  etc . monitoring location setting accuracy ±0.1° IR The IR  wavelength,  808nm Light angle ≥ 25° Irradiation distance 100 m Interface Audio input 1 path（optional ） Audio output 1 path（optional ）  Alarm input 1 path（optional ） Alarm output 1 path（optional ） Interface protocols ONVIF、PSIA、CGI Other specification Temperature  range -40℃～60℃ Relative  humidity ≤ 95%（ 25°C） Atmospheric  pressure 80kpa～106 kpa Material 304 stainless  steel(316, 316L for optional) Supply  voltage AC85V-260V(DC 24V, AC24V for option) Inlet hole specifications 1pcs M25*1.5 output(original G3/4) Electrical  connection RJ45 Ethernet cable and power cable Thermostat  System Optional Installation  method bracket or  base installation Dimension Drawing of Explosion proof PTZ Camera KX-EX1000ZPPS220 Related Accessories of Explosion proof PTZ Camera KX-EX1000ZPPS220 Camera bracket; KX-EX01BY not a must. Explosion proof conduit pipe Explosion proof conduit pipe-304/316L stainless steel explosion proof junction according to project
